macek RFD 2212
Size 12 inch
Type Woofer
Voice coil Configuration Dual
Material Aluminum
Description 3 4-Layer
Cone Material Paper FIBERlock
Frame Material Frame Cast
Material Aluminum
Surround Material Rubber
Description Santoprene BART
Specifications
Power handling(RMS) 500 Watts
Power handling(Peak) 1000 Watts
Impedance 4 Ohms
Sensitivity 88 db
Vas 2.65
Fs 29
Qts .48
Xmax .55
Dimensions
Depth Bottom mount 5.1875 in.
Cutout 10.8125 in.
Displacement 362.88 cu in.
Enclosure Sealed box Recommended Minimum Volume (Cubic Feet) - .8
Recommended Maximum Volume (Cubic Feet) - 4.0
Ported box Recommended Volume (Cubic feet) - 2.0
F3(Hz) - 35
Number of Ports - 1
Port diameter(Inches) - 4
Port Length(Inches) - 10.75
