Amplifier section
Maximum Power Output 43w x 4 (4 ohms)
Frequency Response 15-30,000 Hz+- 1 dB
Output level 2V
Tone Controls
Bass – 100 Hz+-11 dB
Mid – 1 kHz+- 11 dB
Treble – 10 kHz+- 11 dB
Loudness – 20 Hz+14 dB (Volume Level 20)
FM Tuner Section
Frequency Range
USA : 87.5 – 107.9 MHz in 100 kHz steps
Other area – 87.5 – 108.0 MHz in 50-kHz steps
Sensitivity – 15 dBf (IHF)
Signal-to-Noise Ratio – 60 dB (mono)
Stereo Separation – 35 dB
Antenna Input – 75 ohms (Unbalanced)
AM Tuner Section
Frequency Range
USA – 530 – 1,710 kHz in 10 kHz steps
Other area – 531 – 1,602 kHz in 9-kHz steps
Sensitivity – 32 dBu
Signal-to-noise 45 dB
CD Player Section
System – Compact Disc Digital Audio
Sampling frequency – 44.1 kHz
D/A Convertor Type – 1-bit D/A converter with
8-times oversampling digital filer
Frequency Response – 20-20,000 Hz
Total Harmonic Distortion – 0.01% (1 kHz)
