300w bridged maximum output.
Continuous power 50w x 2 into 4 ohms at less than 0.05% THD (20hz - 20khz).
75w x 2 into 2 ohms atv less than 0.5% THD (1kHz).
150w bridged into 4 ohms (1 kHz).
Large capacity, stabilised parallel DC-DC converter power supply with pulse width modulation and 4 power MOS-FETs.
Balanced input isolation circuit for ultra low noise internal signal transmission free of ground noise.
High quality differential drive push-pull amplifier.
Built in 80Hz high and low pass filters: low pass filter for sub woofer connection with bridged output.
Built in 18db/oct low pass filter and v12db/oct high pass filter.
RCA line output terminals for in-line multi amp system.
Tri-mode operation can drive 1,2 or 3 speakers.
2 way operation mode selection: stereo L+R.
Variable input sensitivity to match source unit.
PWM regulated power supply.
Heavy duty gold plated power and speaker terminals.
Gold plated RCA line input/output terminals.
Protection indicator.
Frequency response 5Hz - 50kHz -3db
Input sensitivity 0.3v - 5v
Dimensions (W x H x D) 297 x 56 x 240mm.
Cena? 900Kc?
12.06.2013, 21:14 | tappaja
